Description
Features & Benefits
High Flexibility
Provides 1 phase and 3 phase breaker modules with 16 A and 32 A rating options
Highly scalable design allows tool-less installation of a maximum four breaker modules (optional), and supports a maximum 12 branches
Standard rRPP chassis fits all 1P/3P 16 A / 32 A breaker modules, and easily adapts to power feed requirement changes
High Reliability
Intelligently monitors system /each branch?s status for power usage and viability
Compartmentalized control with separate breaker module and phases
Offers abnormal voltage and current alarms
Provides statistics for system max/min voltage, current, frequency and kW with four hours tracking history
Proactive management from assets with up to 2000 event logs and data trending
Convenience
Configurable alarm notification for over/under current and poor power factor
Each breaker module has LED light for easily identifiable power status
Freely connects to computer with built-in RS-485 or USB port to monitor branch status and parameter configuration
Mini SNMP card (optional) allows remote system/branch monitoring. Provides quick summary with glance view, and detail system/branch power status data are readily available
