Ultron (> 10 kVA) – DPS Series 300-1200 kVA

The Next Generation UPS Answering the Demand of Large Data Centers and Colocations

Delta’s superior Ultron DPS series 300-1200 kVA UPS supports unity output power factor to deliver up to 10 MW power capacity to meet the demands for large data centers and colocations that require higher power capacity. The Ultron DPS series guarantees the highest level of system reliability and resiliency by supporting self-detection of key components with pre-warning function, multilayered redundancy design, and complete power rating coverage. Moreover, the DPS series supports advanced manageability. Key environment parameters, and event analysis can all be monitored via local 10″ LCD monitor and remotely. Along with optional battery management software, the DPS series enables users to achieve predictive maintenance and minimize system downtime, while lowering the total cost of ownership (TCO).

Add to quote

SKU: 88221259 Category: DELTA UPS Tag: UPS

Description

Description

Features & Benefits
Ultimate Availability

Supports up to 10 MW power capacity with the parallel redundancy and expansion up to 8 units
Redundancy components and dual CAN bus ensures system availability
Proactive detection of key component status for early diagnosis on UPS malfunction
Intelligent battery health diagnosis enables better battery maintenance and replacement
Advanced event analysis, including 10,000 event logs, waveform capturing and key paremeters recording, to detect UPS abnomality and ensure higher availability

Excellent Performance

The industry’s leading power density and smallest footprint with the design of both top/bottom cable entry and inbuilt switches
(* For DPS-300K, only top cable entry is available)
Unity output power factor guarantees no-rating and provides 100% kW
AC-AC efficiency of up to 96.5% and 99% in ECO mode resulting in marked energy cost savings
Supports both VRLA and environment-friendly Li-ion batteries

Sophisticated Manageability and Flexibility

User-friendly 10? color touch panel simplifies local UPS management
Environment information, such as security, water, fire, and temperature can be integrated and monitored via the LCD panel of the UPS
If the UPS is equipped with an external battery management system, the battery information can be integrated and monitored via the LCD panel of the UPS
Fully front access and modular design of key components shortens the mean time to repair (MTTR)
Flexible battery quantity of 30-46 pcs achieves optimal battery investment
