Ultron (> 10 kVA) – HPH Gen2 Series 20/30/40 kVA

Combines reliable protection, cost-effective power, compact footprint and high-level performance

The latest HPH Gen2 20-40 kVA UPS offers a best in class footprint and high-level performance. With advanced technology and thermal management, it achieves the world?s leading power density and promises 40?C without de-rating. The 0.99 input PF and iTHD < 2% ensure maximum upstream source compatibility. Low total cost of ownership is achieved by > 96% efficiency, energy recycle mode, wider battery quantity configuration and inbuilt 15 A charger. In addition, it provides a user-friendly interface touch panel, manual protection devices and caster wheels for easy deployment, installation and operation. All these features provide the ideal solution for various small and medium-sized data centers and critical power backups.

Add to quote

SKU: 88221261 Category: DELTA UPS Tag: UPS

Description

Description

Features & Benefits
Easy Deployment and Maintenance with Compact Design

Inbuilt casters for easy move-in, positioning and maintenance
Inbuilt input / bypass input / output / maintenance bypass breakers for completed distribution panel
Slim design and smallest footprint (40 kW in 0.15 m?) to reduce the space wasting

Low Total Cost of Ownership

Wide battery quantity configuration (30-46 pcs) to optimize the battery solution
High AC-AC efficiency over 96% and ECO mode to 99% resulting in marked energy cost savings
Low input harmonic distortion (iTHD < 2%) which is highly compatible with upstream of UPS power without additional filter or over sizing generator High Manageability and Flexibility User-friendly 5" color touch screen enables easy local UPS management Optional SNMP IPv6 and Modbus communication cards for remote monitoring Inbuilt 15 A charger for long backup solution without additional cost Optional IP42 kit for harsh environment application Front access and easy battery replacement for inbuilt battery models
